HOT ROD / STREET ROD
COLLECTION

OE Ford & Chevy Wheel

Raw
(Series 657)

OE Ford  & Chevy - Raw (Series 657)

15" Wheel Prices

SERIES PART NO. SIZE BOLT CIRCLE BACK SPACE PRICE
657 657-5512 15X5 5X4.5 3 $93.00
657 657-5534 15X5 5X4.75 3 $93.00
657 657-5555 15X5 5X5.5 3 $93.00
657 657-5612 15X6 5X4.5 3 3/4 $93.00
657 657-5634 15X6 5X4.75 3 3/4 $93.00
657 657-5655 15X6 5X5.5 3 3/4 $93.00
657 657-5712 15X7 5X4.5 4 1/4 $97.00
657 657-5734 15X7 5X4.75 4 1/4 $97.00
657 657-5755 15X7 5X5.5 4 1/4 $97.00
657 657-5812 15X8 5X4.5 4 1/4 $98.00
657 657-5834 15X8 5X4.75 4 1/4 $98.00
657 657-5855 15X8 5X5.5 4 1/4 $98.00
657 657-5012 15X10 5X4.5 4 1/2 $119.00
657 657-5034 15X10 5X4.75 4 1/2 $119.00
657 657-5055 15X10 5X5.5 4 1/2 $119.00

17" Wheel Prices

SERIES PART NO. SIZE BOLT CIRCLE BACK SPACE PRICE
657 657-8734 17X7 5X4.75 4 5/8 $245.00
657 657-8834 17X8 5X4.75 4 1/2 $258.00
657 657-8934 17X9 5X4.75 5 1/2 $272.00

Additional Custom Backspaces

STANDARD REVERSE
SIZE NEGATIVE POSITIVE NEGATIVE POSITIVE
15X5 3 3 1/2 2 2 1/2
15X6 3 1/2 4 1/2 2 1/8 3 1/4
15X7 4 5 1/4 2 1/4 3 1/2
15X8 4 6 1/4 2 1/4 4 1/2
15X10 4 1/4 8 2 1/2 6
15X12 4 1/4 10 2 1/2 8
15X14 4 1/4 11 1/2 2 1/2 10
16X6 3 1/2 4 1/2 2 1/2 3 1/4
16X7 4 5 1/4 2 1/4 3 1/2
16X8 4 3/4 6 2 1/4 3 1/2
16X10 4 1/4 7 1/2 2 1/2 6
17X7 3 3/4 5 3/4 2 3/4 4 3/4
17X8 4 1/2 6 3/4 2 3/4 5
17X9 5 1/2 7 3/4 2 3/4 5 1/4

NOTE: There is an additional $20 fee for Custom Backspaces.


Additional Information

  • Two piece, all-steel construction.
  • Offered in multi fit and direct fit. See the above Tables or Contact Us for details
  • Offered in Paint Ready and Chrome/Paint Ready so that customer can custom paint.
  • Wheel is shown in Black.
  • Powder coating extra. Contact Us for details.
  • Center cap and trim ring are not included, order separately. See the Caps and Trim Rings page for accessories.
  • Requires conical seat lug nut (Acorn), not included.
  • Custom backspace available. Contact Us for details.
  • Outside knob for cap is 10-1/8".
  • Additional sizes are available: 15X12, 15X14, 16X10, 16X12. Contact Us for details.
  • Wheels primered $15.00 each.
  • ALL SALES FINAL
